Ultra Thin Highlight White 0.56 inch SMD Led 7 Segment Led Display
Features:
High intensity and reliability
High quality, low power requirement
IC compatible, easy assembly
| Product type | SMD 7 segment led tube | |
| Digit number | 2 digit | 1digits~4 digits |
| Digit height | 0.56 inch | 0.2, 0.28,0.3,0.39,0.4,0.51,0.56,0.8(inch) |
| Color | White | red, blue,green, yellow-green, orange,etc. |
| Size | 19*12.4mm | Other size are supported |
| Polarity | Common Cathode | Common Anode |
| Current | 20ma | |
| Free Samples | supported | |
| Lead time for sample | 3-7 working days | Tooling samples are 12-18 working days |
| Lead time for formal order | 15 working days | According to order quantity |
| OEM&ODM | Support | Based on customer’s drawing or idea |
| LOGO printing | Support | Based on customer’s drawing or idea |
Color:
| Led color | Blue | Green | Yellow-Green | Yellow | Amber | Orange | Red | White |
| Wave length(nm) | 465-475 | 515-525 | 565-575 | 585-595 | 600-610 | 620-630 | 635-650 | / |
| Led chip | GaN | GaP | GaP | GaAsP | GaAsP | GaAsP | AlInGaP | GaN+Phosphor |
Absolute Max Rating (25℃, take yellow-green led as sample):
| Symbol | Parameter | Value | Unit |
| PAD | Power Dissipation per segment | 60 | mW |
| VR | Reverse Volrage per segment | 5 | V |
| IAF | Continuous Forward Current per segment | 25 | mA |
| IPF | Peak Forward Vurrent per segment (Duty-0.1, 1KHz) | 80 | mA |
| / | Derating Linear from 25℃ per segment | 0.33 | mA/℃ |
| Topr | Operating Temperature Range | -35~+85 | ℃ |
| Tstg | Storage Temperature Range | -35~+85 | ℃ |
|
|
