    0.39 Inch 4 Digit 7 Segment LED Displays For Electronic Scale

    Ask Lasest Price
    Brand Name : KeRun
    Model Number : KRS-34933AUR-3
    Certification : ROHS,SGS,REACH
    Price : Negotiable
    Payment Terms : T/T, Western Union, MoneyGram, L/C
    Supply Ability : 10000pcs/day
    Delivery Time : 20-25 working days, can negotiate based on order quantity
    • Product Details
    • Company Profile

    0.39 Inch 4 Digit 7 Segment LED Displays For Electronic Scale

    0.39 Inch 4 Digit Ultra Red 7 Segment LED Display For Electronic Scale

    Products features:

    1. Extreme short light response time, high brightness, low power, environment friendly and energy saving.

    2. Can be driven by low voltage and low current.

    3. It is easy to drive and control and therefore is applied widely.

    4. Products are packaged in solid state and therefore are stable and have good air tightness.

    5. Long life span, usually more than 50 thousands hours

    6. For it is universal used, these products can save custom die cost

    7. Products displaying different colors could be produced according to customers’ requirements.


    GENERAL INFORMATION
    Part NO.Chip MaterialEmmting ColorLens TypeDescription
    KRS-34933AUR-3
    InGaN
    ReddiffuseCommon Anode
    Electical/Optical Characteristics atTa=25℃
    ParameterSymbolBlueUnitConditions
    MN.TypM
    Luminous Intensitylv2030mcdF-20mA
    Peak WavelengthApnmIF-20mA
    Dominant WavelengthAD635645nmIF-20mA
    Spectral Line Half WidthAA30nmF-20mA
    Forward VoltageVF1.62.5VF-20mA
    Reverse CurrentIR20uAVe-eV
    Absolute Maximum Ratings atTa=25C
    ParameterSymbolMaximum RatingUnit
    Power DssipationPd50mW
    Forward CurrentIF20mA
    Peak Forward CurrentIF(Peak)80mA
    Reverse VoltageVR5V
    Operating TemperatureTo prMinus -20*c-80°c
    Storage TemperatureTstgMinus -20°c+80°c
    Lead Solder TemperatureTsol260°c for 3~5 seconds
