0.3 Inch Common Anode Ultra Red 7 Segment LED Display Used Indoor
Product Features:
1) Low consumption ,working under low voltage and current .
2) High brightness ,short response time, high frequency.
3) Small size, lightweight, easy soldered ,great Impact resistance.
4) Solid state encapsulation, good stability .
5) Long life ,more than 50,000 hours .
6) Great display effect ,big viewing angle.
| GENERAL INFORMATION | ||||||
| Part NO. | Chip Material | Emmting Color | Lens Type | Description | ||
KRS-3404AUG-3 | AIGaInP | Red | diffuse | Common Anode | ||
| Electical/Optical Characteristics atTa=25℃ | ||||||
| Parameter | Symbol | Blue | Unit | Conditions | ||
| MN. | Typ | M | ||||
| Luminous Intensity | lv | 30 | 50 | mcd | F-20mA | |
| Peak Wavelength | Ap | nm | IF-20mA | |||
| Dominant Wavelength | AD | 568 | 573 | nm | IF-20mA | |
| Spectral Line Half Width | AA | 20 | nm | F-20mA | ||
| Forward Voltage | VF | 1.5 | 2.5 | V | F-20mA | |
| Reverse Current | IR | 20 | uA | Ve-eV | ||
| Absolute Maximum Ratings atTa=25C | ||||||
| Parameter | Symbol | Maximum Rating | Unit | |||
| Power Dssipation | Pd | 50 | mW | |||
| Forward Current | IF | 20 | mA | |||
| Peak Forward Current | IF(Peak) | 80 | mA | |||
| Reverse Voltage | VR | 6 | V | |||
| Operating Temperature | To pr | Minus -20*c-80°c | ||||
| Storage Temperature | Tstg | Minus -20°c+80°c | ||||
| Lead Solder Temperature | Tsol | 260°c for 3~5 seconds | ||||
|
|
